Blum Hinges & Drawers

Blum 973A0500.01x1 973A Blumotion Straight Arm Full Overlay Hinge for Doors, Nickel Finish For use with Blum clip top hinges Automatically adjusts to the closing force of the door Mounting method: clip-on, standard hinge, corner stop Nickel-plated steel

BLUM CLIP Mounting Plate Cruciform, Spacing: 0 mm Material: Steel Finish: nickel plated Fixing: for chipboard screws Distance between fixing positions: 32 mm Distance cabinet front edge to first fixing position: 37 mm Mounting plates height adjustment: with elongated holex

BLUM CLIP Mounting Plate Cruciform, Two part Screw on Spacing: 0 mm Material: Zinc Finish: nickel plated Surface of bottom part: self colour Fixing: for chipboard screws Distance between fixing positions: 32 mm Distance cabinet front edge to first fixing position: 37 mm Mounting plates height adjustment: through lower and upper part/screwsx

BLUM CLIP top BLUMOTION Wide Angle Hinge, for Zero Protrusion 155 Degree Opening angle: 155 Degree Cranking: Overlay application BLUMOTION Boss assembly: Expando Boss material: Steel boss Closing mechanism: with spring Side adjustment: +/- 2 mm Depth adjustment: + 3/- 2 mm, convenient with spiral screw

BLUM CLIP top EXPANDO Hinge, 100° Opening angle: 100° Cranking: Overlay application Boss assembly: EXPANDO Boss material: Steel boss Closing mechanism: with spring Side adjustment: +/- 2 mm Depth adjustment: plus 3/minus 1 mm, with screw

BLUM CLIP top wide angle EXPANDO hinge, 180 Degree Cranking: Overlay application Boss assembly: EXPANDO Boss material: Steel boss Closing mechanism: with spring Side adjustment: +/- 2 mm Depth adjustment: + 3/- 2 mm, convenient with spiral screw

Blumotion Soft Close 973A6000 for 170 degree Hinges (Clip Top) Blum Soft Close Damper Fits Blum Clip on 170/155 degree hinges (hinges not supplied) Zinc Nickel Plated

TANDEM Full Extension BLUMOTION Runner 450mm BLUM TANDEM Runner Full Extension BLUMOTION 450mm

BLUM CLIP top BLUMOTION Standard Hinge, 110 Degree Cranking: Overlay application BLUMOTION Boss assembly: EXPANDO Boss material: Steel boss Closing mechanism: with spring Side adjustment: +/- 2 mm Depth adjustment: + 3/- 2 mm, convenient with spiral screw

BLUM CLIP Mounting Plate Cruciform, Spacing: 0 mm Material: Steel Finish: nickel plated Fixing: Expando (pre-mounted screws with split dowels) Distance between fixing positions: 32 mm Distance cabinet front edge to first fixing position: 37 mm Diametre of fixing holes: 5 mm Drilling depth of fixing holes: 11.5 mm Mounting plates height adjustment: with elongated holex
